Firearms Bore Inspection

DESCRIPTION

• With a Hawkeye® Borescope you can inspect chambers, leades, lands and grooves, gas ports, and crowns from muzzle to breech in rifles and pistols.
• Designed specifically for use in firearms, firearms manufacturers, and forensic scientists
• Images captured on video can be stored and transmitted to other computers or on the Internet.
• Forensic Scientists, use it to determine twist and land count, to examine sound suppressors, and to preserve valuable DNA
• evidence that can link a firearm to a crime.

Technical Specifications:

• The AFB (Adjustable Focus Box)
• version of the Shooting Edition Hawkeye contains an adjustable focus Hawkeye Borescope with enhanced optics, mirror tube for inspecting chambers, lands and
• grooves, gas ports, and crowns, a cleaning kit, and a light source in a laminated box with die-cut foam
• The Luxxor Portable Video Camera (LPC) connects to the eyecup of any Hawkeye Borescope in seconds.
• It produces a still or moving color video image that can be displayed on a monitor. The image can also be displayed on a computer with the addition of a VC-USB2 device.
• The addition of a Hawkeye LED is highly recommended for the shooting application because
• video requires more light than that which is supplied by the Mini Maglite that comes with the Hawkeye Borescope.
• Never replace lamps again! The new Luxxor 35 LED deliverers all the super-bright intensity and whiteness of its metal halide predessessor, the Luxxor 24, but uses long-life LED technology estimated at 50,000 hrs. of life! (Compared to 500 hrs. for metal halide arc lamps). These new lights also have both coarse and fine intensity adjustment, allowing finely controlled dimming with perfect color rendition.
• Images from the Luxxor Portable Camera (LPC) can be captured and stored on a laptop or desk top computer.
• To do so, a VCUSB2 capture device is required
• Mirror Tubes are replacements for those packed in the Shooting Edition Hawkeye Borescopes and are shipped in a box with die cut foam
• Lockable metal carrying case with die cut foam. Order the PCC for 22” Hawkeye Borescopes.

Ballistic Borescope Slim, specialized for Firearm inspection:

Borescope Kit with Focusing Eyepiece. Including Rotatable Tube of 90 deg  and  carrying case.

• WORKING LENGTH:      560 MM
• WORKING DIA:           4.2 MM
• VIEWING DIRECTION:  0 DEG
• FIELD OF VIEW:          42 DEG.
• LIGHT SOURCE:  35 W LED   HIGH QUALITY
•  LIGHT GUIDE OF HIGH TRANSMISSION QUALLITY
•  PORTABLE VIDEO CAMERA OF HIGH RESOLUTION
•  VIDEO TOOL BOX
• LAPTOP UNIT, PRINTER
